Factory-direct steel gratings & stair treads, shipped worldwide
Open Grid Steel Flooring
Open flooring made to order. Welded or press-locked, HDG finish.
Itemized quote within 24 hours · Free drawing review included
In-house weld & press lines
Open grid floors welded or press-locked under one roof
Certified & tested
Reports on request, MTC with every order
Samples in 5–7 days
Production in 15–25 working days
FOB Tianjin
Shipped worldwide, EXW / CIF negotiable
Orientation comparison
Bearing Bars With Traffic vs Across Traffic vs Close Mesh
Two identical open grid steel flooring panels behave completely differently depending on how the grid is laid relative to the traffic. This is the single most common planning error on plant floors — the table below is how we review it before we cut a single bar.
| Dimension | Bearing Bars With TrafficSpecify this | Bearing Bars Across Traffic | Close-Mesh Grid |
|---|---|---|---|
| How a wheel or foot lands | Every load crosses several bearing bars in a row — load shares along the strong axis | Load lands on cross bars spanning the weak way between bearing bars | Load meets a fine grid; either direction works for foot traffic |
| Deflection behavior | Bearing bars bend over the span as designed; deflection stays predictable | Cross bars flex locally, panels feel live and edges rock under wheels | Short clear distances in both directions; very little local give |
| Bar size for the same span | Standard selection, 20×3 mm to 100×8 mm bearing bars | Heavier cross bars are the wrong fix — the grid is still wrong | Press-locked bars down to 11/11 mm centers |
| Support steel spacing | Set by bearing-bar span between supports — designed, not guessed | Same steel below, but the floor still misbehaves under traffic | Denser members shorten the effective span in both directions |
| Underfoot feel | Smooth travel — no cross-bar joints across the walking line | A joint under every step; trip edges and vibration | Heel-proof surface for public traffic in street shoes |
| Typical use | Plant walkways, platforms, open mesh decking over process floors | Only where steel already exists and traffic is light — flag it first | Public plazas, trench covers, areas where solids must not fall through |
| Dengtai supply | In-house — welded or press-locked lines | Cut and oriented to your plan — reviewed in the quote | In-house — press-lock line down to 11/11 mm |
Unsure which way your panels should run? Send your drawings — we will spec it inside the 24-hour quote.
Grid orientation planner
Bearing Bars Run in the Traffic Direction — Here Is Why
An open steel flooring panel is not symmetrical, even when it looks it. The bearing bars span the gap between support steel and carry the floor in bending. The cross bars only hold the bearing bars at their spacing and spread a point load into the neighboring bars.
Point the bearing bars in the direction people and pallet trucks actually travel, and every wheel crosses many bearing bars in a row. Turn the grid 90 degrees and the same wheel lands on cross bars that were never meant to carry it — you feel it as rocking edges, live panels and loose joints long before anything bends for good.
Before you order, walk the route: mark the traffic direction on your plan, lay the bearing bars parallel to it, then set the support steel to the span that movement needs. We check the orientation on every drawing we quote — it is part of the free review.
Plan view. Bearing bars parallel to the traffic arrow; supports perpendicular to the bearing bars at each end.
1 · Set the support steel first
Support spacing is the clear span of the bearing bars — fix it before the panel size, and the bar selection follows. Closer supports mean lighter bars for the same load; wider supports mean heavier bars. Either way, the number belongs in the drawing, not in guesswork.
2 · Read deflection across the span
For the same load and bar, deflection grows with the span far faster than the bar size tames it — one extra support line mid-route usually does more than a heavier section. Tell us the deflection you can accept and we match bars and spans; load tables come with the quote.
3 · Close the edges, fix without welding
Band bars close every cut end of the grid and carry the edge load, and fixing clips hold each panel to the support steel with no site welding. Installation drawings and the fixing layout ship with every order — see clips & fixings.
Why specify open grid
Why Plant Builders Specify Open Grid Steel Flooring
Heavy-duty open flooring
Bearing bars from 20×3 mm to 100×8 mm take foot traffic, pallet trucks and maintenance vehicles on one grid. Specify by span and traffic, not by guesswork — load tables available on request.
Anti-slip open flooring
Serrated bearing bars give wet and oily zones a grip a plain surface cannot — and because water drains straight through the grid, the floor never holds the puddle that causes the slip in the first place.
Custom sizes, samples in 5–7 days
Every open steel flooring panel is cut and banded to your drawings — small trial orders welcome. Check the orientation on a sample panel before you commit the whole floor.
Applications
Where the Grid Orientation Pays Off
Open grid steel flooring earns its place wherever traffic, water and maintenance meet — which is exactly where laying the grid the wrong way gets expensive.
Plant walkways & access routes
Bearing bars laid along the route of travel; spills and wash water fall through as people pass.
Open mesh decking for mezzanines
Open mesh decking lets light and sprinkler water through the level above — plan the traffic lines before the panel sizes.
Wet & process floors
Grid floors over process areas drain through instead of pooling — stainless grades for washdown zones.
Treads & covers in one order
Open flooring, stair treads and trench covers ship together from one factory — one drawing set, one quote.
Specifications
Open Grid Steel Flooring Specifications
| Parameter | Range |
|---|---|
| Bearing bar | 20×3 mm to 100×8 mm, plain or serrated |
| Bar spacing | 30 / 40 / 60 mm centers |
| Cross bar | Twisted square or round, per specification |
| Panel width | Up to 1.25 m |
| Panel length | Up to 6 m |
| Construction | Welded or press-locked grid, banded ends |
| Materials | Q235B carbon steel · SS304 / SS316 stainless |
| Surface | Black or hot-dip galvanized (ASTM A123 / ISO 1461) |
| With every order | Installation drawings and fixing layout included |
Materials & test documents
Every heat of Q235B, SS304 or SS316 enters production with its mill test certificate verified at goods-in — the first of our five QC stages. Panels leave with documentation, not promises:
- Mill test certificate to EN 10204 Type 3.1
- Factory inspection report with every shipment
- Declaration of Conformity prepared per order destination
Load tables with your quote → · Bearing bar options explained →
Standards & compliance
Produced to Recognized Standards — Documents on Request
ANSI / NAAMM MBG 531
Grid panels produced to MBG 531 reference practice, with joint inspection on our five-stage QC plan.
ASTM A123 / ISO 1461 HDG
Open flooring to ASTM A123 as standard — galvanized coating thickness checked by sampling on every batch.
CE & SGS tested
Certified & tested, reports on request — we show documents you can verify, not a certificate wall.
Custom made
Custom Grid Floors, Cut and Banded to Your Drawings
Send your floor plan
Traffic direction, clear spans, support spacing, quantities — or just photos and a sketch. Drawing review is free, and we check the grid orientation first.
Quote within 24 hours
Itemized, FOB Tianjin as standard — EXW or CIF on request. Small trial orders welcome, so you can lay one panel before committing the floor.
Samples in 5–7 days, production in 15–25
Working days after drawing confirmation, hot-dip galvanizing included. Installation drawings and the fixing layout ship with the order.
Factory-direct quote
Get a Factory Quote
Send clear span, support spacing and panel sizes — a factory quote lands within 24 hours, and open flooring, treads & covers go in one order.
- Grid orientation checked on every drawing, free of charge
- DoC, MTC EN 10204 3.1 and inspection report with every order
- Factory audits welcome — see the lines before you commit
Prefer to talk? WhatsApp us or sales@dtsteelladder.com
Request your quote
Five fields — we do the rest.
FAQ
Frequently Asked Questions
Which way should the bearing bars run in open grid steel flooring?
Run the bearing bars in the direction of traffic. Bearing bars span between the support steel and carry the floor load in bending, while cross bars only tie the grid together. Traffic along the bearing bars works on the strong axis of the floor; traffic across the bars lands on cross bars that were never meant to carry a wheel.
What is the lead time for open grid steel flooring?
Samples ship in 5–7 working days and mass production runs 15–25 working days after drawing confirmation, both including hot-dip galvanizing. Rush production in 10–15 days is possible with a surcharge — ask in your quote.
Can I order a small trial quantity, and how is open flooring priced?
Yes — small trial orders are welcome, and open flooring, treads and covers can ship in one order. Pricing is itemized FOB Tianjin, EXW or CIF negotiable, quoted per m² or per ton; we do not publish a fixed price list.
