Close-Mesh Grating
Close mesh grating from in-house lines, flat and strong.
Itemized quote within 24 hours · Free drawing review included
Close mesh on our press line
Press-locked 11 / 11 mm panels made in-house
Certified & tested
Reports on request, MTC with every order
Samples in 5–7 days
Production in 15–25 working days
FOB Tianjin export
Shipped worldwide, EXW / CIF negotiable
Process comparison
Close Mesh vs Welded vs Compound Steel Grating
Close mesh is not simply a welded panel with tighter spacing — at 11 mm pitch the forming process itself changes. Here is how the three routes to a fine steel floor compare, with an honest note on which lines run in our own workshop.
| Dimension | Close-Mesh Press-Locked | Forge-Welded 30 / 40 / 60 | Compound Steel Grating |
|---|---|---|---|
| Forming principle | Notched flat bars mechanically interlocked under press pressure — no welding | Every bearing-bar / cross-bar intersection resistance-forged under heat and pressure | Close-mesh base with a checkered plate (grating with checkered plate) fixed on top |
| Mesh range | Down to 11 / 11 mm clear openings | 30 / 40 / 60 mm centers | 11 / 11 mm base, surface closed by the plate |
| Why it holds at fine pitch | Cold pressing locks each joint without heat — fine bars stay straight, with no weld shadow between such close bars | Fine pitch multiplies the joints to forge; coarser centers stay the efficient choice | The plate carries the load; the mesh keeps the panel light before closure |
| What the floor contains | Heel tips, small tools, fasteners and litter stay on the surface | Water and debris drain fast; small items drop through | Fully closed surface — nothing passes in either direction |
| Panel flatness | Extremely flat — no weld heat, no distortion | Flat panels straight off the line | Plate adds stiffness; the checkered top stays even |
| Typical use | Public and hygiene floors, trench covers, tree pits, facades | Platforms, walkways, trench covers, guardrails | Mezzanine storage floors where nothing may fall through |
| Our lines | In-house — press-lock machine | In-house — electro-forging line | Assembled per project on our lines |
Not sure which mesh your floor needs? Send your drawings — we will spec it inside the 24-hour quote.
Mesh scale comparison
How Fine Is 11 / 11 mm, Really?
Welded grating spans run at 30, 40 or 60 mm centers. Close mesh presses bearing and cross bars onto an 11 / 11 mm pitch — a different order of fineness, drawn to the same scale below.
All four strips are drawn to the same scale — blue bars are bearing bars, gray bars are cross bars. The dashed circle is one heel tip: it drops straight through 60 mm centers, and on the 11 / 11 mm strip it is carried by the bars around it.
What a close mesh keeps on the floor
- Heel tips and narrow shoe edges on public walkways and podium decks
- Small tools and fasteners over mezzanines and plant floors
- Litter and debris in civic spaces — swept off the top, not lost below
- Rain and washdown water still drain — close mesh is open mesh, just fine
Public floors, hygiene floors
The same 11 / 11 mm pitch serves two different buyers. Civic floors specify galvanized close mesh so nothing falls onto whatever is below. Food and chemical plants specify SS304 / SS316 close mesh so solids stay on the floor and out of the drains during washdown.
Q235B hot-dip galvanized for outdoor and municipal duty; SS304 / SS316 stainless for corrosive and hygiene duty — same press-locked geometry, same drawings path.
How panels are made
From Notched Bars to a Fine, Flat Panel
1 · Notching & bar prep
Flat bearing bars are notched at a fine, even pitch and cross bars are set into the notches — the geometry that lets an 11 mm grid stay true across a full panel.
2 · Press-locking
The press closes every notch around its cross bar in one cold pass. Each joint is a mechanical interlock: no weld heat, no weld shadow, no distortion between bars this close together.
3 · Galvanizing or stainless finish
Carbon-steel panels go to a certified galvanizing partner near our mill for ASTM A123 / ISO 1461 hot-dip galvanizing — typically 2–3 days, inside your production window. Stainless panels ship in mill finish for washdown duty.
Why specify close mesh
Why Buyers Specify Close Mesh Grating
Close mesh from in-house lines
Fine-mesh panels are made on our own press-lock line, so pitch, bar sizes and banding follow one drawing — one factory, one point of responsibility from sketch to container.
A flat top that carries the load
With bearing bars at an 11 mm pitch, footfall and pallet loads land on many more bars per meter of floor — a dense, flat top that stays comfortable underfoot in public areas. High-load aisles simply specify thicker flat bars: the pitch stays 11 mm while the capacity rises.
Samples and small orders welcome
Close mesh samples ship in 5–7 working days, and small trial orders are welcome before a full container. Your quote arrives itemized, within 24 hours.
Applications
Where Close Mesh Grating Works
Fine open mesh that still drains — specified wherever whatever falls needs to stay on the floor.
Trench covers & tree pits
Municipal channels that keep litter, heels and leaves out while rain passes through.
Public walkways & podiums
Pedestrian floors over plant rooms and basements, with heel-proof geometry at 11 / 11 mm.
Food & washdown floors
SS304 / SS316 fine mesh lets washdown water through and keeps solids out of the drains.
Facades & screens
An even 11 mm pitch reads as a fine architectural texture on ventilated facades.
Specifications
Close Mesh Grating Specifications
| Parameter | Range |
|---|---|
| Construction | Press-locked — notched flat bearing and cross bars, mechanically interlocked |
| Clear openings | Down to 11 / 11 mm (bearing × cross) |
| Bearing bars | Flat bars, size set per load specification |
| Materials | Q235B carbon steel · SS304 / SS316 stainless |
| Surface | Hot-dip galvanized (ASTM A123 / ISO 1461) or stainless mill finish |
| Panel size | Cut and banded to your drawings |
| Edge detail | Banded edges; clips, frames and toe plates supplied alongside panels |
| Fixing | Fixing layout and installation drawings included |
Materials & test documents
Every heat of Q235B, SS304 or SS316 enters production with its mill test certificate verified at goods-in — the first of our five QC stages. Panels leave with documentation, not promises:
- Mill test certificate to EN 10204 Type 3.1
- Factory inspection report with every shipment
- Declaration of Conformity prepared per order destination
Load tables & calculators → · Heel-proof geometry explained →
Standards & compliance
Produced to Recognized Standards — Documents on Request
ANSI / NAAMM MBG 531
Press-locked panels produced to MBG 531 reference practice, with joint and dimension checks on our five-stage QC plan.
ASTM A123 / ISO 1461 HDG
Galvanized coating thickness checked by sampling on every galvanized batch before panels are released.
CE & SGS tested
Certified & tested, reports on request — we show documents you can verify, not a certificate wall.
Custom made
Custom Close Mesh Panels, Cut and Banded to Your Drawings
Send your drawing
Panel sizes, mesh pitch, bar sizes, quantities — or just photos and a sketch. Drawing review is free.
Quote within 24 hours
Itemized, FOB Tianjin as standard — EXW or CIF on request. Close mesh grating from small MOQ, trial orders welcome.
Samples in 5–7 days, production in 15–25
Working days after drawing confirmation, hot-dip galvanizing included. Installation drawings and fixing layout ship with the order.
Factory-direct quote
Get Your Close Mesh Grating Quote
Get your close mesh grating quote — factory direct, with a reply within 24 hours. Send mesh pitch, panel sizes and quantities; drawing review is free.
- Five-stage QC, from MTC verification at goods-in to final inspection
- DoC, MTC EN 10204 3.1 and inspection report with every order
- Factory audits welcome — see the press line before you commit
Prefer to talk? WhatsApp us or sales@dtsteelladder.com
Request your quote
Five fields — we do the rest.
FAQ
Frequently Asked Questions
What openings does close mesh grating have?
Press-locked close mesh runs down to 11 / 11 mm clear openings — bearing and cross bars at the same fine pitch. That is fine enough to carry heel tips, small tools and litter, while water and cleaning fluids still drain through.
Stainless or galvanized — which close mesh should I choose?
Use hot-dip galvanized Q235B for outdoor municipal floors, trench covers and tree pits; use SS304 or SS316 for food, chemical and washdown floors where chlorides or cleaners are present. Both are made on the same press-lock line.
What is the lead time for close mesh grating?
Samples ship in 5–7 working days and mass production runs 15–25 working days after drawing confirmation, both including hot-dip galvanizing. Shipped worldwide from Tianjin Port — FOB Tianjin as standard, EXW or CIF negotiable.
