Factory-direct steel gratings & stair treads, shipped worldwide
Custom Bar Grating
From drawing to delivery: custom steel grating made in one factory.
Itemized quote within 24 hours · Free drawing review included
One factory, start to finish
Forming, cutting, banding and packing under one roof
Certified & tested
Reports on request, MTC EN 10204 3.1 per batch
Samples in 5–7 days
Production in 15–25 working days
FOB Tianjin
Shipped worldwide, EXW / CIF negotiable
Stock vs custom
What Changes When Bar Grating Is Made to Your Drawing
Stock designations are convenient, but most projects need something slightly different. Here is exactly which dimensions we can move when custom bar grating is cut and banded to your drawings — and which ones come from our real forming range.
| Dimension | Stock bar grating | Custom bar grating |
|---|---|---|
| Ordering basis | Published designation, e.g. 19W4 | Your drawing, sketch or old-panel sample — reviewed free |
| Bearing bar | Fixed section per designation | 20×3 mm to 100×8 mm, plain or serrated, matched to your load |
| Bar spacing | 30 / 40 / 60 mm centers | Non-standard centers within our forming range, quoted per project |
| Panel size | Mill-standard panels, trimmed on site | Cut to size up to 1.25 m × 6 m, holes and notches made in-shop |
| Edges & finish | Plain ends, black or galvanized | Banded edges optional; black, painted or HDG (ASTM A123 / ISO 1461) |
| Order size | Full bundles | Small trial orders welcome, first article inspected before the run |
Not sure which bar section your loads need? Send your drawings — we will spec it inside the free review that comes with every 24-hour quote.
The drawing-to-panel path
From Your Drawing to Banded Panels in Four Steps
1 · Send your drawing
PDF or photo of your layout — sizes, bar direction, cutouts. A site sketch and loads are enough to start.
2 · Quote within 24 hours
We mark up your drawing, propose bar sections and spacings, and return an itemized quote — FOB Tianjin as standard.
3 · Sample in 5–7 days
A sample panel confirms geometry, banding and finish before the run — inspected as the first article on our five-stage QC plan.
4 · Production in 15–25 days
Working days after drawing confirmation, hot-dip galvanizing included. Installation drawings and fixing layout ship with the order.
Why order custom direct
Why Buyers Order Custom Bar Grating Factory-Direct
One factory, no hand-offs
Custom grating formed, cut, notched, banded and packed in one workshop — nothing between your drawing and the panel except our own people.
Any size within a real range
Cut-to-size bar grating up to 1.25 m wide and 6 m long, with non-standard spacings and bar sections taken from our forming range — not a catalogue of maybe.
Quick-turn samples, small MOQ
A custom sample panel in 5–7 working days, small trial orders welcome — prove the fit before you commit to the full run of custom steel grating.
What we customize
The Four Things a Custom Grating Order Can Change
Every custom grating enquiry comes down to some mix of these four. Tell us which ones matter and we do the rest.
Panel size & shape
Rectangles, notched corners, curved edges — panels cut to your opening instead of trimmed on site.
Bar pitch & section
Non-standard centers between our range limits, bar heights from 20×3 mm to 100×8 mm, plain or serrated.
Holes, notches & cutouts
Pipe penetrations, cable ways and edge notches positioned from a fixed edge on your drawing, made before finishing.
Banding & finish
Banded edges for pedestrian comfort, then black, painted or hot-dip galvanized to ASTM A123 / ISO 1461.
Before you send
What Your Drawing Needs on It
A complete drawing turns into a firm quote in one pass. Mark these seven items and your custom bar grating enquiry moves straight to pricing.
- Overall length × width of every panel type, with tolerances where they matter.
- Bearing bar direction — which way the bars span. The single most important mark on the sheet.
- Bar section and spacing you expect — or just the load and clear span, and we propose both.
- Holes and notches, each dimensioned from one stated edge of the panel.
- Banding and edges — which edges get banded trim, and any end plates or nosings.
- Material and finish — Q235B black or galvanized, SS304 or SS316 for corrosive duty.
- Quantities per panel mark and the destination port for loading calculations.
No drawing yet?
That is the normal starting point, not a problem. Any of these gets the drawing-to-panel path moving:
- Photos of the panels being replaced, with a tape measure in frame
- A site sketch with spans and loads, however rough
- Just the use and the clear span — we draft the panel and confirm with you
We mark it up into a proper panel drawing and confirm it with you before anything is cut. Start with what you have →
Specifications
Custom Bar Grating: The Range Behind Every Quote
| Parameter | Range |
|---|---|
| Bearing bar | 20×3 mm to 100×8 mm, plain or serrated |
| Bar spacing | 30 / 40 / 60 mm standard; non-standard on request |
| Panel width | Up to 1.25 m |
| Panel length | Up to 6 m |
| Fabrication | Cut to size, holed, notched and banded in-shop |
| Materials | Q235B carbon steel · SS304 / SS316 stainless |
| Surface | Black, painted, or hot-dip galvanized (ASTM A123 / ISO 1461) |
| Order basis | Made to drawings; 19W4 stock equivalents available |
Materials & test documents
Every heat of Q235B, SS304 or SS316 enters production with its mill test certificate verified at goods-in — the first of our five QC stages. Custom runs carry the paperwork with them:
- Mill test certificate to EN 10204 Type 3.1, test data per batch
- Factory inspection report with every shipment
- Declaration of Conformity prepared per order destination
Standards & compliance
Custom Panels Produced to Recognized Standards
ANSI / NAAMM MBG 531
Custom panels produced to MBG 531 reference practice — state the standard you need on your drawing and it goes on the job card.
ASTM A123 / ISO 1461 HDG
Galvanized coating thickness checked by sampling on every galvanized batch before custom panels are released.
CE & SGS tested
Certified & tested, reports on request — documents you can verify, including test data for custom steel grating per batch.
Custom made
Small Trial Orders, Honest Lead Times
Send your drawing
Panel sizes, bar direction, cutouts — or photos and a sketch. Drawing review is free, always.
Quote within 24 hours
Itemized, FOB Tianjin as standard — EXW or CIF on request. Small trial orders welcome.
Samples in 5–7 days, production in 15–25
Working days after drawing confirmation, hot-dip galvanizing included. Installation drawings and fixing layout ship with the order.
Factory-direct quote
Send Us Your Drawings
Send your drawings for custom steel grating — reply in 24 hours, samples in 5–7 days.
- Free drawing review inside the 24-hour quote, sketch or CAD file
- Five-stage QC, from MTC verification to first-article and final inspection
- Factory audits welcome — see the lines before you commit
Prefer to talk? WhatsApp us or sales@dtsteelladder.com
Request your quote
Five fields — describe the panels, we do the rest.
FAQ
Frequently Asked Questions
What should be on my custom bar grating drawing?
Panel length and width, the bearing bar direction, the bar section and spacing if you know them, plus any holes or notches measured from a fixed edge. Missing some of it? Send loads and clear spans instead — we propose the bar sizes, and the drawing review is free inside the 24-hour quote.
Can you make non-standard bar spacings and sections?
Yes. Standard centers are 30, 40 and 60 mm and bearing bars run from 20×3 mm to 100×8 mm, plain or serrated. Non-standard spacings within that forming range are quoted per project, and test data for custom steel grating is provided per batch.
Do you accept small trial orders of custom grating?
Yes — small trial orders are welcome, with a sample panel in 5–7 working days and production in 15–25 working days after drawing confirmation. Full-container orders are calculated per loading plan, FOB Tianjin as standard.
