Serrated Steel Bar
Serrated steel bar teeth bite wet or oily soles. Fewer slips.
Bars alone or built into panels · Itemized quote within 24 hours · Free drawing review included
In-house weld & press lines
Bars joined into panels under one roof
Certified & tested
Reports on request, MTC with every heat
Samples in 5–7 days
Production in 15–25 working days
FOB Tianjin
Shipped worldwide, EXW / CIF negotiable
Bar-top comparison
Serrated, Plain or Twisted: Three Ways a Bar Meets a Sole
Most anti-slip enquiries come down to one component decision: which top surface should the walking surface be? Here are the three bar geometries we supply — each orderable as loose bars or inside panels.
| Dimension | Serrated Steel Bar | Plain Bearing Bar | Twisted Bar |
|---|---|---|---|
| Surface geometry | Teeth sheared along the top edge of a flat bar | Smooth flat top with square edges | Continuously twisted square bar — every face is an edge |
| How it meets a sole | Tooth edges run across the walking direction and catch the tread in series | Depends on the sole and any film between it and the steel | Presents a fresh edge along the whole bar length |
| Where it earns its keep | Wet, oily or frosty zones — stairs, ramps, outdoor walkways | Dry, clean or washdown floors that are swept or hosed | Close-mesh pedestrian floors and trench covers |
| Drainage & debris | Open mesh still sheds liquid; teeth add small crevices to clean | Easiest surface to sweep and hose down | Fine mesh sheds water but holds smaller debris |
| Bar role | Bearing bar in welded panels, tread surface on stairs — or a loose bar | Bearing bar where footing is not the issue | Cross bar in welded and press-locked panels |
| Order format | Bars alone, cut to length, or built into panels | Same formats, any bar size | Supplied as the cross bar of a panel order |
Not sure which top your zones need? Send your drawings — we will spec it inside the 24-hour quote.
How the tooth works
The Serrated Edge, Described as Geometry
1 · One toothed edge per bar
Serration is a cutting step, not a coating: the top edge of the flat bar is sheared into a repeated tooth profile before the bar is welded or packed. The profile repeats along the full length, so every footfall that crosses the bar meets the same series of small ramps.
2 · Teeth work across the walking direction
A toothed bar grips soles that cross it. On a wet or oily floor, the thin film that separates a smooth bar from footwear is interrupted by tooth edges standing in the tread's path, while the open mesh lets the liquid fall through. Bar direction is therefore part of the specification — we confirm it in the quote.
3 · Same section, same load path
Teeth change the top surface, not the section that carries load. Depth and thickness still govern span and load, so specifying a serrated top never downsizes the bar — you order the same 20×3 mm to 100×8 mm section you would order plain, with the tooth added to the walking face.
That is as far as we go: we describe serration as geometry and make no slip-coefficient or slip-test claims. What we can hand you is the mill certificate for the exact heat your bars were cut from.
Why order the bar from the mill
Why Fabricators Order Serrated Steel Bars From the Mill
Your choice: teeth or plain
Every bar size in the range comes with a toothed or a plain top — mixed within one cutting list or one panel if your zones differ. Walkways covered either way.
Serrated steel bar + mill cert
Bars are cut from verified heat lots of Q235B, SS304 or SS316. The mill test certificate to EN 10204 Type 3.1 travels with the order — per heat, batch tested, reports on request.
Any size, cut to your lengths
Sections from 20×3 mm to 100×8 mm, supplied as loose bars for your own framing or built into panels on our lines — one order, one itemized quote, no middlemen.
How to specify
Specifying Serrated Bars in a Panel Order — or Ordering Bars Alone
Either way you are buying the component. Four decisions on your drawing tell us exactly what to cut:
Which bars
Default is teeth on every bearing bar. Alternating toothed and plain bars are possible where a partially smooth line is wanted — mark the pattern on the drawing.
Which face
Teeth belong on the walking face. If panels can be fitted either way up, say so — the toothed side is called out on the installation drawing that ships with the order.
Which section & pitch
Bar depth and thickness from 20×3 to 100×8 mm at 30 / 40 / 60 mm centers. Span governs depth, load governs thickness — we check both in the free drawing review.
Bars alone, or in panels
Fabricators who frame their own supports can order bars only — same mill, same MTC, packed and bundled to your cutting list.
The same component finishes a run of steel serrated anti-slip channel — a drainage cover where the walking surface is the bar itself. Send the channel profile and we quote bars and covers together.
Specifications
Serrated Steel Bar Specifications
| Parameter | Range |
|---|---|
| Bar section | 20×3 mm to 100×8 mm, toothed or plain top |
| Tooth position | Sheared into the top edge, full bar length |
| Bar spacing in panels | 30 / 40 / 60 mm centers |
| Cross bars | Twisted square or round, per specification |
| Panel size | Up to 1.25 m wide × 6 m long |
| Bars-only supply | Cut to your cutting list, bundled for export |
| Materials | Q235B carbon steel · SS304 / SS316 stainless |
| Surface | Black or hot-dip galvanized (ASTM A123 / ISO 1461) |
| Stock designation | 19W4 serrated and custom equivalents |
Material traceability, bar by bar
Bars are cut from verified heat lots — Q235B, SS304 or SS316 — each entering production with its mill test certificate checked at goods-in, the first of our five QC stages. What leaves with your order:
- Mill test certificate to EN 10204 Type 3.1, per heat
- Factory inspection report with every shipment
- Declaration of Conformity prepared per order destination
Standards & compliance
What We Document — and What We Do Not Claim
ANSI / NAAMM MBG 531
Panels built with serrated bearing bars are produced to MBG 531 reference practice, with joints checked on our five-stage QC plan.
ASTM A123 / ISO 1461 HDG
Galvanized serrated bars are sampled for coating thickness before release, so the teeth keep their profile under the coating.
CE & SGS tested
Certified & tested, reports on request — documents you can verify, not a certificate wall.
Serration itself we keep as geometry: no slip coefficients, no claimed test regime. If your project specifies one, ask in your quote and we will say plainly what we can and cannot provide. Standards hub →
Custom made
Send a Cutting List or a Panel Drawing — Either Works
Send your bar schedule
Sections, toothed or plain tops, lengths, quantities — or full panel drawings if we do the framing. Review is free.
Quote within 24 hours
Itemized, FOB Tianjin as standard — EXW or CIF on request. Small trial orders welcome, wholesale or single project.
Samples in 5–7 days, production in 15–25
Working days after confirmation, hot-dip galvanizing included. For panel orders, installation drawings and fixing layout ship with the goods.
Factory-direct quote
Ask for a Serrated Steel Bar Quote Today
Ask for a serrated steel bar quote today — an itemized offer lands within 24 hours, free drawing or cutting-list review included, and samples are ready in 5–7 working days.
- Five-stage QC, from MTC verification at goods-in to final inspection
- DoC, MTC EN 10204 3.1 and inspection report with every order
- Factory audits welcome — see the lines before you commit
Prefer to talk? WhatsApp us or sales@dtsteelladder.com
Request your quote
Five fields — we do the rest.
FAQ
Frequently Asked Questions
Can I order serrated steel bars on their own, without panels?
Yes — bars-only supply is a normal enquiry. Send a cutting list with bar size, toothed or plain top, lengths and quantities, and we quote it like any panel order: itemized, FOB Tianjin, with the mill test certificate for every heat used.
Which bars in a panel can be serrated?
Any bearing bar can carry teeth on its top edge. Most orders serrate every bearing bar; alternating patterns are possible where a partially smooth walking line is preferred. Tell us which bars and which face in your drawing and we confirm it in the quote.
What is the lead time for serrated steel bar orders?
Samples ship in 5–7 working days and production runs 15–25 working days after the cutting list or drawing is confirmed, hot-dip galvanizing included. Rush production in 10–15 days is possible with a surcharge — ask in your quote.
