Deck construction
Open Grating Deck vs Solid Plate on a Bridge
On an exposed footbridge deck the flooring itself does the drainage work. Here is how an open metal bridge grating deck compares with a solid steel deck — and an honest note on where each belongs.
| Dimension | Open grating deck | Solid plate deck |
|---|---|---|
| Rain & drainage | Rain and slush fall straight through the open mesh — no ponding on the cross-fall | Water runs off only on the camber; low spots pond and freeze |
| Dead load | Open mesh puts less steel on the deck — lighter loading for footbridge stringers | Solid plate adds dead load and often heavier framing |
| Grip in wet weather | Serrated bearing bars give underfoot bite as geometry, wet or dry | Plate depends on a rolled tread pattern or added coating |
| Wind on exposed spans | Air passes through the deck — reduced uplift on elevated crossings | Solid panels take the full wind load |
| Debris & upkeep | Leaves and grit drop through; the deck stays clear and visible | Debris collects on top and needs sweeping |
| Traffic framing | Pedestrian crowds and light maintenance vehicles — our standard framing | Vehicular road bridge decks: quoted per project with structural data |
Solid plate is still the right answer where wheels cross small openings — we quote those positions per project too. Not sure which framing fits your crossing? Send your drawings — we will spec it inside the 24-hour quote.
How the deck behaves
How a Drain-Through Bridge Deck Works
1 · Water goes through, not across
Openings between bearing bars let rain and wash water drop straight through the deck, so the walking surface never carries a film of water — no ponding, no frozen sheets on the cross-fall.
2 · Lightweight open flooring
Open-mesh panels carry the same pedestrian duty with less steel per square metre than a solid deck — a lighter dead load for the bridge structure to carry in the first place.
3 · Hot-dip galvanized for exposure
Bridge decks live in wind, rain and de-icing spray. Panels go to a certified galvanizing partner near our mill for ASTM A123 / ISO 1461 hot-dip galvanizing — typically 2–3 days, already counted inside your production window.
Why specify open deck panels
Why Specifiers Choose Metal Bridge Grating
Anti-slip underfoot, serrated or plain
Choose serrated bearing bars for wet or icy crossings or plain bars for a smoother pedestrian surface. Anti-slip here is geometry — teeth cut into the bar surface — not a coating that wears away.
Safe and load-rated for real traffic
Pedestrian crowds plus light maintenance vehicles is our standard framing — specify by span and traffic, and we match bar height, thickness and spacing to it. Load tables are available on request.
Built to last, factory-direct
One factory, from bearing bar to galvanized finished panel — factory-direct FOB Tianjin pricing, custom sizes from small MOQ, and test data for your batch on request.
Applications
Where Metal Bridge Grating Works
Drain-through open flooring wherever people cross on foot — over water, roads, plant floors and storage levels. Vehicular road decks are handled honestly, per project.
Pedestrian & footbridge decks
Drainage-through decking for footbridges and cycle crossings — rain passes straight through, nothing ponds on the slope.
Maintenance access walkways
Inspection gangways and service crossings framed for pedestrians and light maintenance vehicles, galvanized for exposure.
Mezzanine grating decks
The same open panels serve as mezzanine grating flooring — plant traffic above, light and sprinklers passing through below.
Road bridge decks — per project
Vehicular bridge decks are quoted individually with structural data — spans, wheel loads, fixing layout — under heavy-duty designations.
Specifications
Metal Bridge Grating Specifications
| Parameter | Range |
|---|---|
| Bearing bar | 20×3 mm to 100×8 mm, plain or serrated |
| Bar spacing | 30 / 40 / 60 mm centers |
| Cross bar | Twisted square or round, per specification |
| Panel width | Up to 1.25 m |
| Panel length | Up to 6 m |
| Materials | Q235B carbon steel · SS304 / SS316 stainless |
| Surface | Black or hot-dip galvanized (ASTM A123 / ISO 1461) |
| Panel format | Welded standard; press-locked close mesh optional |
Materials & test documents
Every heat of Q235B, SS304 or SS316 enters production with its mill test certificate verified at goods-in — the first of our five QC stages. Deck panels leave with documentation, not promises:
- Mill test certificate to EN 10204 Type 3.1
- Factory inspection report with every shipment
- Declaration of Conformity prepared per order destination
Load tables & calculators → · Galvanized options explained →
Standards & compliance
Produced to Recognized Standards — Documents on Request
ANSI / NAAMM MBG 531
Deck panels produced to MBG 531 reference practice, with weld inspection on our five-stage QC plan.
ASTM A123 / ISO 1461 HDG
Galvanized coating thickness checked by sampling on every galvanized batch before deck panels are released.
CE & SGS tested
Certified & tested, reports on request — we show documents you can verify, not a certificate wall.
Custom made
Custom Deck Panels, Cut and Banded to Your Drawings
Send your deck drawings
Panel sizes, spans, traffic framing, quantities — or just photos and a sketch. Drawing review is free.
Quote within 24 hours
Itemized, FOB Tianjin as standard — EXW or CIF on request. Small trial orders welcome, bulk mezzanine grating runs equally quotable.
Samples in 5–7 days, production in 15–25
Working days after drawing confirmation, hot-dip galvanizing included. Installation drawings and fixing layout ship with the order.
Factory-direct quote
Get a Factory Quote
Ask for a metal bridge grating quote today — reply in 24h, samples in 5–7 days. Send deck sizes and quantities and an itemized quote lands within 24 hours, free drawing review included.
Pedestrian and maintenance decks are standard framing; road bridge decks are quoted from your structural data.
- Five-stage QC, from MTC verification at goods-in to final inspection
- DoC, MTC EN 10204 3.1 and inspection report with every order
- Factory audits welcome — see the lines before you commit
Prefer to talk? WhatsApp us or sales@dtsteelladder.com
Request your quote
Five fields — we do the rest.
FAQ
Frequently Asked Questions
What is the lead time for metal bridge grating?
Samples ship in 5–7 working days and mass production runs 15–25 working days after drawing confirmation, both including hot-dip galvanizing. Rush production in 10–15 days is possible with a surcharge — ask in your quote.
Can you quote vehicular road bridge decks?
Yes — but per project. Pedestrian crowds and light maintenance vehicles are our standard deck framing; vehicular road bridge decks are quoted individually once you share spans, wheel loads and fixing layout, so panels are matched to the structural data.
How is metal bridge grating shipped and priced?
Shipped worldwide from Tianjin Port — FOB Tianjin as standard, EXW or CIF negotiable. Pricing is itemized per m² or per ton in your quote; we do not publish a fixed price list.
